Modern and Mid-Century Modern CAD Symbols - Preview Page

Available to download NOW!

Below you will find previews for all the CAD block symbols of included in this AutoCAD Modern design block library.

Mid century modern clocks AutoCAD symbols

Above are the Mid Century Modern clock CAD symbols from world famous designers. Included in this set is the 1947 George Nelson Bubble Clock, the 1957 George Nelson Eye Clock, the George Nelson Spindle Clock, Sunflower Clock, and more.

AutoCAD Symbols Mid Century Modern Lighting

Beautiful modern and mid-century modern pendant and hanging CAD lighting symbols which includes the Le Klint lk172 pendant designed in 1969 by architect Poul Christainsen, the 1958 ph5 pendant lamp by Poul Henningsen.

Mid Century Modern AutoCAD Lighting CAD Blocks

Above - the complete collection of modern and mid-century modern CAD lighting symbols. Included are CAD blocks of Nelson Bubble Lamps. Plus, a bonus in the image above are the AutoCAD cross-hairs... which I think is just funny!

CAD Symbol Eames Lounge Chair Ottoman

Above - CAD symbols for the Eames Lounge Chair and Ottoman. Designed by Charles and Ray Eames in 1956. The CAD blocks of this Eames lounge chair include plan, side, rear, and front views. This lounge chair and ottoman are still manufactured to this day by Herman Miller.

AutoCAD Drawings Mid Century Modern Chairs

Above - This is all the CAD symbols for modern and mid-century modern chairs. The library includes front, top, side, and rear views of le Corbusier chairs, CAD symbols for the Barcelonia Chair designed by Mies van der Rohn in 1929, the George Nelson Coconut Chair designed in 1955, the Wassily Lounge Chair designed by Marcel Breuer in 1925, and many more CAD furniture symbols.

CAD Symbols Modern Mid-Century Modern Sofas Sectionals CAD Symbols

Above you will see the modern design sofa and sectionals AutoCAD furniture blocks.

CAD Symbols Mid Century Modern Design Tables

Above - The CAD blocks library for modern and mid century modern dining tables, coffee tables, and CAD symbols for Eames stools.


Download this AutoCAD Modern and Mid-Century Modern CAD symbols Library Now!

To return to the ArchBlocks Modern / Mid Century Modern Furniture Blocks Library product page click on the arrow below;
